Qirun supplies Mn18Cr2 manganese steel toothed roll shells for coal, limestone, and mineral crushing applications. These wear-resistant castings are designed for compatible toothed roll crushers, where the working teeth grip and fracture incoming materials through compression and shearing forces.
Mn18Cr2 high manganese steel offers impact toughness and work-hardening capability under suitable crushing conditions. Qirun supports custom tooth profiles, shell dimensions, and mounting configurations based on crusher models, technical drawings, and replacement part requirements.
Parameter | Specification |
|---|---|
Product Name | Mn18Cr2 Toothed Roll Shells |
Brand | Qirun |
Main Material | Mn18Cr2 High Manganese Steel |
Product Category | Double Roller Crusher Parts |
Product Type | Toothed Roll Crusher Shell |
Equipment | Compatible Toothed Roll Crushers |
Material Properties | Impact Toughness, Work Hardening, Wear Resistance |
Shell Outer Diameter | According to Customer Drawings |
Shell Inner Diameter | According to Customer Drawings |
Shell Length | Customized |
Tooth Height & Pitch | According to Crusher Design |
Mounting Configuration | According to Roll Assembly |
Manufacturing | Casting, Heat Treatment & Machining as Required |
Applications | Coal, Limestone & Mineral Crushing |
OEM Support | Custom Tooth Profiles, Dimensions & Replacement Castings |
Inspection | Material and Dimensional Checks as Agreed |
Final dimensions, material composition, installation requirements, weight, and compatible crusher models must be confirmed according to approved technical drawings.
Mn18Cr2 manganese steel provides toughness for crusher components exposed to repeated mechanical loading.
This material is suitable for selected roll crushing applications where impact and compression are significant operating factors.
Appropriate casting quality and heat treatment help develop the material properties required for demanding crushing environments.
High manganese steel can increase its working surface hardness under sufficient repeated impact and compressive stress.
This work-hardening behavior helps the crushing teeth resist wear while maintaining toughness beneath the working surface.
Actual performance depends on crushing pressure, feed material, alloy composition, and operating conditions.
The toothed surface helps grip incoming feed and draw material into the crushing zone.
Qirun supports custom tooth configurations according to crusher design requirements.
Available customization specifications may include:
Tooth height and pitch
Tooth width and spacing
Tooth working face geometry
Shell thickness and overall dimensions
Mounting surfaces and installation features
The final tooth profile should match the crusher configuration and required feed characteristics.
Toothed roll shells are installed on compatible crusher roll assemblies.
Their internal dimensions and mounting features must match the existing equipment.
Qirun supports replacement casting requirements based on original component drawings, dimensions, and customer specifications.
Qirun provides custom manganese steel casting and machining support for crusher wear components.
Customers can submit roll shell drawings, crusher models, or existing part specifications for technical review.
Mn18Cr2 is a chromium-alloyed high manganese steel used in selected impact-resistant wear components.
Its main characteristics include impact toughness and the ability to develop surface hardness under appropriate loading conditions.
Feature | Mn18Cr2 Manganese Steel | High Chromium Cast Iron |
|---|---|---|
Main Advantage | Impact Toughness | Abrasion Resistance |
Work-Hardening Capability | Yes | Not the Primary Wear Mechanism |
Impact Tolerance | Generally Higher | Generally Lower |
Wear Behavior | Benefits from Impact and Compression | Benefits from Hard Chromium Carbides |
Application Focus | Impact-Intensive Crushing | Selected Abrasive Crushing Conditions |
Material Selection | Based on Load and Work-Hardening Conditions | Based on Abrasion and Impact Limits |
Material performance depends on specific chemical composition, heat treatment, crusher design, and operating conditions.
Qirun provides OEM manufacturing support for manganese steel toothed roll shells.
Our customization services can include:
Mn18Cr2 material specifications
Custom outer and inner diameters
Shell length and thickness requirements
Tooth profiles, heights, and spacing
Mounting holes, keyways, and installation surfaces
Replacement components based on technical drawings
Heat treatment and machining requirements
Inspection according to agreed specifications
Please provide the following details:
Crusher manufacturer and model
Existing roll shell drawing or part number
Outer diameter, inner diameter, and shell length
Tooth height, tooth pitch, and tooth profile
Required material grade
Feed material and crushing application
Estimated order quantity and delivery requirements
These details help Qirun evaluate component compatibility and manufacturing specifications.
Looking for wear-resistant toothed roll shells for coal or limestone crushers?
Qirun supplies Mn18Cr2 manganese steel crusher castings and customized replacement roll shells for mining and industrial crushing applications.
Send us your crusher model, roll shell drawings, tooth specifications, or material requirements to discuss OEM manufacturing and quotation details.
